传感器在智能电网行业的应用和重要性
作者: 时间:2020-08-11 14:29 阅读数:

  传感器的典型应用就是在电力行业对于感知电网、采集电网运行参数、获取设备运行状态及保护电力系统的稳定运行等方面开展了大量的研究,对于电力系统中重要的设备和系统提出了有效可行的传感器应用解决方案。

  The typical application of sensors is to carry out a lot of research on sensing power grid, collecting grid operation parameters, obtaining equipment operation status and protecting the stable operation of power system in the power industry. Effective and feasible sensor application solutions are proposed for important equipment and systems in power system.

  传感器在电网中应用主要集中在变电站自动化、电力设备状态监测及光缆电缆线路故障监测和定位等方面。电压电流互感器及测量单元是典型的电磁型传感器,主要利用ROGOWSKI线圈实现高电压大电流的测量;在电厂、电站主要使用电阻应变式传感器、热电式传感器和流量传感器等,实现发电机过热监测与诊断等。

  The application of sensors in power grid is mainly concentrated in substation automation, power equipment condition monitoring and optical cable line fault monitoring and positioning. Voltage and current transformer and measuring unit are typical electromagnetic sensors, which mainly use Rogowski coil to measure high voltage and large current; in power plant and power station, resistance strain sensor, thermoelectric sensor and flow sensor are mainly used to realize overheat monitoring and diagnosis of generator.


  在输变电领域主要使用温湿度传感器、拉力传感器、三维加速度传感器、风速传感器及振动传感器等实现线路状态测量;在变电站系统里主要使用磁电式传感器、温度传感器、电压传感器及液位传感器等实现变压器油量测量、铁心温度测量,合、分闸线圈电流监测等。

  In the field of power transmission and transformation, it mainly uses temperature and humidity sensor, tension sensor, three-dimensional acceleration sensor, wind speed sensor and vibration sensor to realize line state measurement; in substation system, it mainly uses magnetoelectric sensor, temperature sensor, voltage sensor and liquid level sensor to realize transformer oil measurement, core temperature measurement, closing and opening coil current monitoring Etc.

  光纤传感器目前国内外都已经开发出实现电流测量的系列化设备,可用于500kV及以下电压等级、35kA电流范围电网的参量测量。光纤传感器在高压输电网故障诊断上也有应用。随着光纤传感技术发展,利用分布式光纤传感技术可以实现位移、应力、应变及温度等物理量的测量,在电网的发电机组、大型变压器及开关设备等状态监测上都有应用。

  At present, the optical fiber sensor has developed a series of current measurement equipment at home and abroad, which can be used for the parameter measurement of power grid with voltage level below 500kV and current range of 35ka. Optical fiber sensors are also used in high voltage transmission network fault diagnosis. With the development of optical fiber sensing technology, the measurement of displacement, stress, strain, temperature and other physical quantities can be realized by using distributed optical fiber sensing technology. It has been applied in the condition monitoring of generator sets, large-scale transformers and switchgear in power grid.

  光纤传输网在线监测系统,对传输网的所有光设备、ODF端口、光纤及接头盒内的熔接点管理和监测,分析光纤的性能和传输质量等智能电网建设愿景意味着需要扩展电网的信息感知深度和监测的范围。

  The optical fiber transmission network online monitoring system manages and monitors all optical devices, ODF ports, optical fibers and fusion points in the joint box of the transmission network, and analyzes the performance and transmission quality of optical fiber. The vision of smart grid construction means that the information perception depth and monitoring range of power grid need to be expanded.

  除了增强原有的自动化业务、保护业务及设备运行状态检修等业务类型外,电力系统还需要完善管理自动化、运维自动化、设施防护智能化、故障定位智能化及监测空间立体化等新功能的信息需求。

  In addition to enhancing the original automation business, protection business and equipment operation status maintenance and other business types, the power system also needs to improve the information requirements of new functions such as management automation, operation and maintenance automation, intelligent facilities protection, intelligent fault location and three-dimensional monitoring space.
